Pepperl+Fuchs safety Light grid LGM17
2024-11-07 03:16 Sales Khanewal 27 views Reference: 10989
Location: Khanewal
Salary: 1 ₨
Pepperl+Fuchs safety Light grid LGM17
Measuring automation light grid with beam spacing of 17 mm, IO-Link interface, push-pull output, fixed cable with M12 plug
overviews
Automation light grids in the LGM Series are designed to measure small to large objects. The slimline light grids are modular in design and are available with various beam gaps and field heights. The entire signal evaluation process is carried out within the device. The lightweight systems can be integrated elegantly into their surroundings, from both a technical and a visual perspective. As a result, machines and plants operating in temperature ranges between -30 °C ... +60 °C can be designed to more compact dimensions.
Please contact me get more information
Email:Mia@cwlyautomation.com
VK/Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com
Effective detection rangeStandard : 0.3 ... 6 m
Threshold detection range7.5 m
Light sourceIRED
Light typemodulated infrared light , 850 nm
Field heightsee Table 1, max. 3200 mm
Beam crossoverFactory setting: three beam crossing, deactivateable
Beam blankingadjustable max. 2 fixed suppressible beam areas (blanking)
Beam spacing16.67 mm
Number of beamssee Table 1, max. 193
Operating modeEmitter: Emitter power adjustable in two ranges
Optical resolutionwithout beam crossover: 17 mm
with beam crossover: 8.5 mm with in 25% and 75% of the range
Opening angle10 °
Ambient light limit> 50000 Lux (if external light source is outside the opening angle)
Please contact me get more information
Email:Mia@cwlyautomation.com
VK/Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com
LGM8-100
LGM8-200
LGM8-300
LGM8-400
LGM8-500
LGM8-600
LGM8-700
LGM8-800
LGM8-900
LGM8-1000
LGM8-1100
LGM8-1200
LGM8-1300
LGM8-1400
LGM8-1500
LGM8-1600
LGM8-1700
LGM8-1800
LGM8-1900
LGM8-2000
LGM8-2100
LGM17-100
LGM17-200
LGM17-300
LGM17-400
LGM17-500
LGM17-600
LGM17-700
LGM17-800
LGM17-900
LGM17-1000
LGM17-1100
LGM17-1200
LGM17-1300
LGM17-1400
LGM17-1500
LGM17-1600
LGM17-1700
LGM17-1800
LGM17-1900
LGM17-2000
